Picture of Crosby® 1018428 Anchor Shackle, 1 ton Load, 3/8 in, 0.44 in Dia Screw Pin, Self-Colored
Picture of Crosby® 1018428 Anchor Shackle, 1 ton Load, 3/8 in, 0.44 in Dia Screw Pin, Self-Colored

Crosby® 1018428 Anchor Shackle, 1 ton Load, 3/8 in, 0.44 in Dia Screw Pin, Self-Colored

Manufacturer: Crosby Group
Crosby® Anchor Shackle, Series: Maxtough® S-209, 1 ton Load, 3/8 in Size, 0.44 in Pin Diameter, Screw Pin, 1.44 in Inner Length, 1.03 in Inner Width, 0.66 in Opening, 0.91 in Eye Outer, 2.49 in Overall Length, 2.02 in Overall Width, Carbon Steel Body, Alloy Steel Pin, Self-Colored
SKU: CRO 10-18428
Manufacturer part number: 1018428
Availability:
Total Stock Available : 80
Price: Call for pricing
i h h



Have Questions About This Product?



  • Forged quenched and tempered with alloy pins
  • Working load limit and grade "6 in permanently shown on every shackle
  • Shackles can be furnished proof tested with certificates to designated standards, such as ABS, DNV, Lloyds or other certification
  • Approved for use at -40 to 204 deg C
  • Capacities 1/3 thru 55 metric tons, grade 6
  • The tests are conducted by Crosby® and 3.1 test certification is available upon request
  • +/-0.13 in L tolerance
  • +/-0.06 in W tolerance
  • Fatigue rated
  • Load rated
Products specifications
Product type Consumable
Size 3/8
Weight 0.31
Body Material Carbon Steel
Eye Outer Size 0.91
Inner Length 1.44
Inner Width 1.03
Load Capacity 1
Opening Size 0.66
Overall Length 2.49
Overall Width 2.02
Pin Diameter 0.44
Pin Material Alloy Steel
Pin Type Screw
Series Maxtough® S-209
Finish Self-Colored
